NEC offers LT power cables which include armoured and unarmoured cables as per IS:1554 P-1 and IS:7098 P-1 with PVC and XLPE insulation respectively with aluminium or copper conductor.
For international markets, we offer cables as per BS:5467 and as per IEC:60502-1 generally known as NYY cable.
Application:
Power Cables are used underground, in cable trays etc. for interconnections and transmission of power in industries, power plants, projects and all other electrical installations. It connects power supply to residential, commercial & industrial units.
Aluminium / Copper Armoured / Unarmoured Power Cables
1C / 2C / 3C / 3.5C & 4C Cables.
Special Characteristic
Energy efficient Cables range…
| Core Details | Range |
|---|---|
| 1 Core | 1.5 to 630Sq. mm. |
| 2 Core | 1.5 to 630Sq. mm. |
| 3 Core | 4.0 to 400Sq. mm |
| 3.5 Core | 25 to 400Sq. mm. |
| 4 Core | 4.0 to 400Sq. mm. |
Solid / Stranded 99.7% pure annealed electrolytic grade copper / aluminium conductor.
Insulation PVC or XLPE.
Armoured / Unarmoured - AL/GI round wire / AL/GI flat strip.
Inner Sheath PVC (ST-1 & ST- 2) / FR-LSH/ LSZH.
Outer Sheath PVC (ST-1 & ST- 2) / FR-LSH/ LSZH.
Heavy duty performance.
Best combination of safety, efficiency & economy.
